SKD-37
SKD-37
SKD-35
One switch control one pump
Function Description
● Suitable for automatic liquid level,pressure control and protection of three-phase deep well pumps,submersible sewage pumps,etc.,Power range is 0.75-15kw;
● It can manually or automatically control the water pump;
● Multiple working modes:can be connected to float switches, liquid level probes,and electrical contact pressure gauges,suitable for the vast majority of situations;
● With undervoltage/overvoltage protection function;
● Equipped with overload protection function;
● With short-circuitprotection function;
● If the voltage reduce from 380v to 220v, it will protectthe water pumpfrom damaged;
● Can avoid probe dry rotation protection;
● High definition LCD digital display of voltage and current values;
● LCD displays fault information and acoustic alarm;
● Can be configured according to user requirements;
MULTIPLE CONTROL METHODS
● Electric contact pressure gauge;
● Pressure sensor;
● Float switch;
● Liquid level probe;
● Pressure switch.
